professional power amplifier
Update: 2015/4/16 View:
- Brand: CTW
- Type: DA
- Price: RMB
- Promotion: RMB ( 0 Customers Bought)
Introduction
| odel No | High Power, High Performance Power Amplifier DA5000 | |
| CLASS-TD | ||
| TECHNICAL SPECIFICATION | 8Ω sound track power | 1500W |
| 4Ω sound track power | 2400W | |
| 2Ω sound track power | 4800W | |
| 16Ω sound track power | 3000W | |
| 8Ω bridge power | 4800W | |
| 4Ω bridge power | 9600W | |
| Total harmonic distortion | <0.05% | |
| Signal noise ratio | >108dBA(20Hz to 20KHz) | |
| Damping ratio | >2500(20Hz to 20KHz) | |
| Conversion rates | 30V/μs | |
| load impedance | 10KΩ | |
| Indicator light | Two 6 LED multifunctional display colum | |
| Input Connector | XLR JACK | |
| efficiency | 85%(RMS) | |
| Output Connector | NL4 Speakon | |
| Size (H×W×D) | 483×44×450mm | |
| N.W. | 9Kg | |
| input voltage | 90-265V AC (50/60Hz) |
